Distillation is a process for chemical and microbiological purification of raw water by gas-liquid reform and separation. In the process, water is evaporated, in which produced steam breaks away from water, and unevaporated water flowing to behind is dissolved with solids, non-volatile substances and macromolecular impurities. In the distillation process, low-molecular impurities may be entrained and carried in evaporated steam in the form of water mist or droplets, so it needs separation device to remove tiny water mist and entrained impurities, including endotoxin. Purified steam becomes water for injection after condensation. Distilling method can reduce at least 99.99% of endotoxin content.
Technical parameters
Model |
WFI capacity(kg/h) |
Pure steam capacity(kg/h) |
Heating power (kw) |
E-MEWS100-4/50 |
100 |
50 |
36 |
E-MEWS100-4/100 |
100 |
100 |
100 |
E-MEWS100-4/60 |
200 |
60 |
60 |
E-MEWS100-5/100 |
200 |
100 |
100 |
E-MEWS100-5/100 |
300 |
200 |
100 |
E-MEWS100-5/200 |
300 |
200 |
200 |
E-MEWS500-5/100 |
500 |
100 |
100 |
E-MEWS500-5/150 |
500 |
150 |
150 |
E-MEWS500-6/200 |
500 |
200 |
200 |
