Laboratory water bath LX-0700N

Category:Laboratory > Other Instrument > Other Laboratory Equipment / Supplies
Product Name:Laboratory water bath LX-0700N
Price(USD):0.00
International Approvals/Standards:ISO
Company:Wuxi Guanya Refrigeration Technology Co., Ltd. (LNEYA)

Basic Info
  • Factory Location: Add: No.10, Zhenfa No.1 Road, Shuofang Street, New District, Wuxi, Jiangsu ,China.Zip code 214142

    Main Sales Markets: North America,Central/South America,Western Europe,Eastern Europe,Australasia,Asia,Middle East,Africa

  • Monthly Production Capacity: 1

    Contract Manufacturing: CRO

    Packaging Information: standard wooden case

  • Delivery Lead Time: 25 working days

    Sample Provided: yes

    Payment Terms: TT

    Technical Parameters:

    Model

    LX-0250N

    LX-0400N

    LX-0700N

    LX-1000N

    LX-1450N

    LX-2000N

    Medium Temperature Range

    -15℃~30℃

    -25℃~30℃

    -25℃~30℃

    -25℃~30℃

    -25℃~30℃

    -25℃~30℃

    Temp. control

    ASET multifunctional controller

    Temp. control optional

    Heat-conducting medium outlet temp. control

    communication protocol

    MODBUS RTU Protocol,  RS 485 Interface

    Temp. feedback

    Heat-conducting medium temperature feedback PT100

    Cooling capacity

    0℃

    1.5kW

    2.4kW

    4kW

    7.5kW

    10kW

    15.5kW

    -10℃

    1kW

    1.5kW

    2.7kW

    6.3kW

    8kW

    12kW

    -20℃

    0.55kW

    0.8kW

    1.5kW

    3.5kW

    5kW

    7.3kW

    Circulation pump

    Max20L/min

    0.7BAR

    Max20L/min

    0.7BAR

    Max35L/min

    1BAR

    Max50L/min

    1BAR

    Max75L/min

    1BAR

    Max75L/min

    1BAR

    capacity of liquid storage

    15L

    25L

    30L

    35L

    45L

    60L

    Compressor

    Tecumseh

    Tecumseh

    Copeland

    Copeland

    Copeland

    Copeland

    Evaporator

    copper tube

    Operating controller

    7-inch color touch screen, temperature curve record, excel-format export

    Security protection

    Self-diagnosis function; freezer overload protection; high pressure switch;

    overload relay, thermal protection device etc. security protection function.

    Refrigerants

    R-404A

    Connection size

    DN-15

    DN20

    DN20

    DN20

    DN20

    DN-20

    Product size (air-cooled)

    400*600*1050

    400*600*1150

    500*680*1350

    550*680*1450

    620*680*1550

    750*750*1750

    Weight (air-cooled)

    115KG

    145kg

    180kg

    225kg

    290kg

    340kg

    Power

    AC220V 50HZ

    1.5kW (max)

    AC220V 50HZ

    2.2kW (max)

    AC220V50HZ

    3.5kW (max)

    AC380V 50HZ

    4kW (max)

    AC380V 50HZ

    5kW (max)

    AC380V50HZ

    6.5kW (max)

    Material

    Cold rolled steel

    Optional

    Circulation Pump Optional: 35L/min 2.5bar 50L/min 2.5bar 110L/min 2.5bar

    Optional

    SUS304 material

    Optional

    Pressure max. 10 bar circulating pump

    Optional Power

    220V 60HZ three-phases, 440V~480V 60HZ three-phases

    Remark

    Can make the bigger capacity of water storage as required.
